Paper Plate Making Machine
|
Payment Terms |
L/C, T/T at sight |
|---|---|
|
Power |
15000W |
|
Voltage |
380 |
|
Stroke |
70-120 times/min |
|
Area |
2500*1070*1950mm |
Product Description
About Paper Plate Making Machine
Paper plate making machine is an automated machine designed to produce disposable paper plates quickly and economically. It automatically feeds the paper, heats and shapes the plates, cuts, counts, and stacks them, producing high-quality products with less manual labor. The machine is made strong with PLC control and a stable paper feeding system that improves productivity and reduces waste.
Appearance
Model: BJ-SPT500Y
Machine brief:
BJ-SPT500Y double workplaces paper plate (dish) forming machine is independently research and developed according to the market. It’s for plates in big sizes and deeper depth. It have many functions of automatic paper-feeding, heating forming, automatic outputting, constant temperature control, automatic counting and collecting. It’s an ideal equipment for producing round plates, square plates in production line. And the machine can equipped with cylinder or hydraulic according to customers’ requirements.
Remark:
| Price term | FOB Ningbo Port, China |
| Payment term | T/T, 30% By 100% T/T , 30% of deposit in advance, 70% balance before shipment. |
| Delivery time | 20-25 working days will be shipment after received the deposit and confirmed the samples /drawings |
| Package | Ply W: Ply Wooden Case / Ply Wooden Tray |
| Guarantee | One year warranty: During this period, if any issues with the machine arise due to manufacturing defects and not improper operation, the seller will repair, replace, or provide spare parts free of charge. After one year, spare parts will be supplied to the buyer at cost. |
| Installation and test running of machine | We will send our technician to install, test run, and train the operator according to the customer’s requirements. All expenses abroad, including visa, round-trip airfare, food, hotel, local transportation, translator, and worker salary (USD 80/day), must be covered by the buyer. |
Technical specifications:
| Type | BJ-SPT500Y Hydraulic Press Paper Plate Making Machine |
| Suitable material: | 100-600gsm base paper, cardboard, ivory board, aluminum foil paper, or other materials. |
| Production speed: | 70-120pcs/min (double workplaces) |
| Blank paper size: | Max paper unfold diameter size 300x300mm |
| Plate specification: | 5inch to 11inch |
| Total power: | 15KW (include hydraulic) |
| Total weight: | 1200KGS |
| Overall dimension: | 2500*1070*1950mm |
| Packing dimension: | 2600x1150x2100mm |
| Power source: | 380V, 50HZ,3PH |
Main Electrical Parts:
| MAIN ELECTRICAL PARTS LIST: （BRAND） | |
| 1) Frequency converter | GTAKE，CHINA |
| 2) Programmable controller: | DELTA , TAIWAN |
| 3) PLC power: | Meanwell, TAIWAN |
| 4) Touch panel : | ykhmi, China |
| 5) Photo electronic sensors: | Autonics, Korea |
| 6) A.C contactor : | Chint, China |
| 7) Small breaker | Chint, China |
| 8) Button: | Chint, China |
| 9) Temperature control | Chint, China |
| 10) Switch power | Meanwell, TAIWAN |
Features of Paper Plate Making Machine1. The machine body frame was made by two pieces of thicker iron plate and optical axis, without welding. This design ensures higher precision, improved stability during operation, and a longer service life. 2. PLC control panel with touch screen. 3. The machine uses mechanical working for paper-feeding, making it more stable than traditional feeding technology and greatly reducing the rejection rate. 4. The machine with humanized design, automatic counting system and collection, it can save more human resource than traditional machine. 5. The machine can equipped with packing machine(paper plates packaging film) and labeling machine(the label after packaging). It’s suitable for production line. |
Main Differences and Advantages:
1)Our R&D team, consisting of highly experienced engineers and designers, is constantly improving and perfecting our machines without pause.
2) Feeding system: Flat feeding with auto delivery function that can guide the paper to the mold, if there is paper jam, the machine will stop.
3) Custom order – Fast Hydraulics, 150mm working distance, air 0.2~0.8mpa, 5 tons pressure can meet with round and square paper plate forming, save air but use more electricity.
4) Our machine has a fresh frame style, using two iron plates of 2cm thickness. The plates are accurately lathed by CNC for the exact screw holes. After applying a baked varnish surface, it fasten the plates with an optical axis. This design significantly improves the standard welded frame by offering greater weight, stability, and a longer service life.
5) We offer free training and after sales service as optional services.
6) Electrical parts, PLC, Convertor, photoelectrical sensor, etc.
Paper Plate Samples
For any inquiries or support, feel free to reach out to us. Our team is always ready to assist you with any questions, technical support, or additional information you may need!
FAQs on Paper Plate Making Machine
- What is Paper Plate Making Machine?
A paper plate machine is a machine system that is used for the manufacture of disposable paper plates. It is used to automate the process of paper feeding, heating, forming, cutting, counting, and stacking in one operation.
- What types of plates can this machine produce?
The machine can produce both round and square paper plates of various sizes and depths depending on the mold used.
- Is the Paper Plate Making Machine easy to operate?
Yes, the machine is designed for easy operation with a PLC control panel and touchscreen interface for simple adjustments. - What is the warranty period for Paper Plate Making Machine?
Typically, the machine comes with 1 year warranty for mechanical and electrical parts, with additional support options available.
